Levenhuk 500T trinocular microscope

The Levenhuk 500T is a trinocular laboratory microscope with a magnification range of 40x to 1000x. It is equipped with wide-field achromatic optics, which delivers clear, sharp images. Thanks to the halogen illumination used, the resulting image colors are true to life, and the details of the observed samples are sharp and clear. This microscope is a valuable instrument for work in a research laboratory, medical center, or veterinary office.

The head consists of an inclined viewing component and a vertical tube for mounting a digital camera (not included in the kit). The head can be rotated 360°. The kit includes two widefield eyepieces and four achromatic objectives with various magnification levels. The sharpness of the optics is adjusted using coarse and fine focus knobs located on the base of the microscope. This microscope is designed for brightfield observations. The 100x objective can be used for oil immersion observations. To protect the front lens, the 40x and 100x objectives have a spring-retractable mechanism.

The stage features a mechanical micrometer, which helps you quickly and accurately position the observed sample under the objective lens. Beneath the stage is a height-adjustable brightfield Abbe condenser. There is an iris diaphragm and a filter holder. The illumination system consists of a halogen bulb with a collecting lens. The powerful bulb provides bright, even illumination of the work area. Illumination brightness is adjustable. The power supply is supplied by a mains adapter.

Characteristics:

• Trinocular rotating head with a tube for mounting a digital camera
• Wide-field achromatic optics with a magnification range of 40–1000x
• Halogen illumination with collector lens, brightness adjustment, AC power supply
• Condenser with iris diaphragm and adjustable height
• Coarse and precise focusing, metal body
• Slot for installing an analyzer (not included in the kit)

The kit includes:

• Microscope
• Achromatic objectives 4x, 10x, 40xs, 100xs (oil)
• WF10x/18mm eyepieces (2 units)
• Abbe condenser NA 1.25 with iris diaphragm and filter holder
• Filters: blue, green, yellow
• Fuse
• C mount
• Bottle of immersion oil
• Power cable
• Protective cover
• User manual and lifetime warranty
